Corrugated Corten Steel Cladding Panels & Facade

Corten steel cladding creates this living architecture. Unlike conventional materials that fade or deteriorate, weathering steel develops a rich, protective patina that transforms from warm orange-brown to deep, earthy purples and russets over time. It's a material that tells the story of its environment, responding to sun, rain, and air to create a uniquely beautiful facade. Whether wrapping an entire building in industrial elegance, creating a dramatic feature wall, or providing a sustainable rain screen system, AHL Corten cladding elevates architectural vision into timeless reality. It's not just a building envelope—it's a statement that ages gracefully, requiring no painting, no sealing, and no compromise.
Material Type:
Corten Metal Siding
Thickness:
0.5-2.0mm
Width:
200-1000mm
Fasteners:
Wall, fascia, and other application
Share :
Corten Metal Siding Panel
Introduction

AHL Corten Steel Cladding Panels are precision-fabricated architectural facade solutions engineered for durability, aesthetics, and performance. Manufactured from premium weathering steel (Corten A/A588), these panels develop a stable, self-protecting patina that eliminates the need for painting or ongoing maintenance while providing exceptional weather resistance. Available in various thicknesses, finishes (natural weathering, accelerated patina, sealed), and profiles (flat, corrugated, custom-formed), our cladding systems accommodate diverse architectural requirements.

Product Information
Corten Architectural Cladding Applications

Technical Specification



Specification
Standard Options Custom Available
Material
Weathering Steel (Corten A / A588 / A242) Yes
Thickness
1.5mm, 2.0mm, 2.5mm, 3.0mm, 4.0mm, 5.0mm Yes
Panel Sizes
Up to 3000mm x 1500mm (larger available) Yes (any project dimensions)
Profiles
Flat, corrugated, micro-rib, custom-formed Yes
Finishes
Natural weathering, accelerated patina, sealed, coated Yes
Edge Detailing
Square edge, folded edges, beveled, mitered Yes
Perforation Options
Custom laser-cut patterns available Yes
Fastening Systems
Concealed clip, exposed fastener, cassette Custom engineered
Corrosion Resistance
Meets ASTM A242 / A588 standards Enhanced for coastal environments
Fire Rating
Class A1 (non-combustible) N/A




Key Features & Benefits


Feature
Benefit
Premium Corten Steel Construction
Develops beautiful, self-protecting patina; never needs painting or sealing.
Exceptional Durability
Withstands harsh weather, UV exposure, temperature extremes, and coastal conditions.
Low Maintenance
No repainting, resealing, or special care required over decades of service.
Sustainable Material
100% recyclable; long lifespan reduces replacement frequency.
Natural Aesthetic Evolution
Patina deepens and enriches over time—never looks "worn out."
Fire Resistance
Non-combustible material (Class A1) for enhanced building safety.
Versatile Design Options
Various profiles, finishes, and installation patterns available.
Rain Screen Compatibility
Ventilated cavity reduces thermal bridging and manages moisture.
Custom Fabrication
Panels manufactured to exact project specifications.




Cladding Profiles & Patterns


Profile Type
Description Best For
Flat Panels
Clean, smooth surface; minimalist aesthetic Modern facades, feature walls, interiors
Corrugated / R Panel
Classic industrial ribbed pattern Warehouse conversions, industrial aesthetics
Micro-Rib / Slimline
Fine, subtle ribbing for texture without bold lines Contemporary architecture
Cassette Panels
Self-contained panels with folded edges Rain screen systems, high-end commercial
Shiplap / Board & Batten
Horizontal or vertical plank effect Residential, warm modern aesthetic
Custom-Formed
Unique profiles to match architectural vision Signature buildings, iconic projects
Perforated
Laser-cut patterns for visual interest, shading Screens, sun control, decorative elements




Applications & Creative Uses


Application
Description
Building Facades
Full-building exterior cladding for commercial, residential, institutional projects.
Feature Walls
Accent walls highlighting entrances, lobbies, or public spaces.
Rain Screen Systems
Ventilated facade systems with moisture management and thermal benefits.
Column Cladding
Wrapping structural columns in Corten for visual continuity.
Soffits & Ceilings
Underside applications for covered outdoor areas.
Interior Feature Walls
Dramatic interior accents for lobbies, restaurants, retail.
Fencing & Screening
Large-scale privacy screens and boundary definitions.
Retail & Hospitality
Brand-defining exteriors for restaurants, hotels, stores.
Cultural Institutions
Museums, galleries, public buildings requiring distinctive identity.
Residential Architecture
Private homes seeking unique, low-maintenance exteriors.

Why Choose Corten Metal Siding?



1.  Corten metal siding develops a distinctive rust-like appearance over time, which gives it a rugged and industrial look.

2. The weathering process of Corten metal siding creates a stable, rust-like appearance that is resistant to further corrosion.

3. Corten metal siding is designed to withstand various environmental conditions, including exposure to rain, snow, and wind.

4. Corten metal siding panel is often made from recycled materials and is fully recyclable, making it an environmentally friendly option for siding.



Installation: Install over a solid substrate

Environmental Considerations: Not recommended for use near salt spray environments or in locations with frequent rain, as these conditions will shorten the product's lifespan

Underlayment: Use a high-temperature underlayment

Rust Development: The material is pre-rusted; the panels are not afraid of being exposed to the weather

Acid Washing: Acid washing will degrade steel performance
