Large Corten Outdoor Water Feature Wall UK

Introduce

Specification

Frequently Asked Questions

Application

project

Introduce

This is a large-scale Corten steel water feature designed for maximum visual and acoustic impact. With overall dimensions of 3050mm height and 2000mm width, this substantial water wall creates a dramatic cascading water effect across its entire surface. Constructed from premium weathering steel, it develops a stable, self-protecting patina that eliminates the need for painting or ongoing maintenance. The integrated recirculating pump ensures effortless operation, while optional LED lighting allows you to enjoy the feature day and night. The self-contained design requires no external plumbing—simply fill with water, plug in, and enjoy. Ideal for luxury residences, hotels, corporate headquarters, and public spaces requiring a high-impact, low-maintenance water feature.

Specification

AHL-WF01

Garden Water Feature

Name: Waterfall Herb Planter Water Feature

Size(MM): 890(H)*720(W)*440(D)

Surface: rusted and unrusted

AHL-WF02

Garden Water Feature

Name: Rain Curtain Water Feature

Size(MM): 1800(W)*250(D)*1800(H);pot: 2000(W)*500(D)*500(H)

Surface: rusted and unrusted

AHL-WF03

Garden Water Feature

Name: Rain Curtain Water Feature

Size(MM): 2400(W)*250(D)*1800(H); pot: 2500(W)*400(D)*500(H)

Surface: rusted and unrusted

AHL-WF04

Garden Water Feature

Name: Outdoor Waterfall

Size(MM): 1800(W)*250(D)*1800(H); pot: 2000(W)*500(D)*500(H)

Surface: rusted and unrusted

AHL-WF05

Garden Water Feature

Name: Rain Curtain Water Feature

Size(MM): 800(W)*250(D)*1800(H); pot: 1000(W)*500(D)*500(H)

Surface: rusted and unrusted

AHL-WF06

Garden Water Feature

Name: Rain Curtain Water Feature

Size(MM): 1800(W)*250(D)*1800(H); pot: 2000(W)*500(D)*500(H)

Surface: rusted and unrusted

AHL-WF07

Garden Water Feature

Name: Corten steel water fountain

Size(MM): fountain: 1000(W)*1200(H); pond: 1500(W)*400(D)

Surface: rusted and unrusted

AHL-WF08/09/10

Garden Water Feature

Name: Corten steel water fountain

Size(MM): 1000(D)*740(H)/1200(D)*740(H)/1500(D)*740(H)

Surface: rusted and unrusted

AHL-WF11/12/13

Garden Water Feature

Name: Corten steel water table

Size(MM): 800(L)*800(W)*400(H)/1000(L)*1000(W)*400(H)/1200(L)*1200(W)*400(H)

Surface: rusted and unrusted

AHL-WF14/15/16

Garden Water Feature

Name: Corten steel water table

Size(MM): 600(L)*600(W)*700(H)/600(L)*600(W)*1000(H)/600(L)*600(W)*1300(H)

Surface: rusted and unrusted

AHL-WF17

Garden Water Feature

Name: Corten steel water table

Size(MM): 1000(L)*2500(W)*400(H)

Surface: rusted and unrusted

AHL-WF18

Garden Water Feature

Name: Corten steel lily bowl

Size(MM): 800(D)*500(H)

Surface: rusted and unrusted

AHL-WF19

Garden Water Feature

Name: Corten steel water feature

Size(MM): 1500(H)*1500(W)*450(D)

Surface: rusted and unrusted

AHL-WF20

Garden Water Feature

Name: Vertical Water Wall with LED lights

Size(MM): 1750(W)*400(D)*1800(H)

Surface: rusted and unrusted

AHL-WF21

Garden Water Feature

Name: Rain Curtain Water Feature

Size(MM): 1200(H)*1200(W)*180(D)

Surface: rusted and unrusted

AHL-WF22

Garden Water Feature

Name: Vertical Water Wall with LED lights

Size(MM): 1750(W)*400(D)*1200(H)

Surface: rusted and unrusted

AHL-WF23

Garden Water Feature

Name: Vertical Water Wall with LED lights

Size(MM): 1000(W)*100(D)*2000(H); pot: 2000(W)*500(D)*500(H)

Surface: rusted and unrusted

AHL-WF24

Garden Water Feature

Name: Fountain & Pond

Size(MM): 650(H)*330(W)*550(D); pond: 1000*1000*200

Surface: rusted and unrusted

AHL-WF25

Garden Water Feature

Name: Fountain & Pond

Size(MM): 1524(H)*1219(W)*495(D)

Surface: rusted and unrusted

AHL-WF26

Garden Water Feature

Name: Rain Curtain Water Feature

Size(MM): 1200(W)*120(D)*1500(H)

Surface: rusted and unrusted

AHL-WF27

Garden Water Feature

Name: Rain Curtain Water Feature

Size(MM): 330(W)*550(D)*650(H)

Surface: rusted and unrusted

AHL-WF28

Garden Water Feature

Name: Round Waterfall Fountain

Size(MM): 1250(D)*1250(H)

Surface: rusted and unrusted

AHL-WF29

Garden Water Feature

Name: Rain Curtain Water Feature

Size(MM): 1500(H)*1500(W)*450(D)

Surface: rusted and unrusted

AHL-WF30/31/32

Garden Water Feature

Name: Corten steel freestanding pond

Size(MM): 2000(L)*250(D)*1200(H)/2500(L)*250(D)*1200(H)/3000(L)*250(D)*1200(H)

Surface: rusted and unrusted

AHL-WF33

Garden Water Feature

Name: Corten steel water bowl

Size(MM): 1000(D)*800(H)

Surface: rusted and unrusted

Key Features

Feature	Benefit
Imposing 3050mm x 2000mm Size	Creates a dramatic, high-visibility focal point visible from across any landscape
Premium Corten Steel Construction	Develops a beautiful, self-protecting rust patina; 4-8x more corrosion-resistant than ordinary steel
Smooth, Even Water Curtain	Precision-engineered weir ensures uniform water flow across the full 2000mm width
Integrated Recirculating System	Self-contained reservoir and pump; no constant water connection needed
Optional LED Lighting	Available in warm white, cool white, or RGB color-changing for dramatic nighttime effects
Low Maintenance	No painting or sealing required; simple seasonal maintenance
Extreme Weather Resistance	Withstands -40°F to 120°F; designed for year-round outdoor use
Custom Sizing Available	Can be scaled to fit your specific space requirements

Detailed Specifications Table

Specification	Details
Model Number	WF03
Product Type	Corten Steel Water Wall / Water Feature
Overall Width	2000 mm
Overall Height	3050 mm
Overall Depth / Projection	500 mm
Water Basin Depth	300 mm
Material Thickness	Customizable (2.0mm - 6.0mm)
Material	Weathering Steel (Corten A / ASTM A588)
Finish	Natural rust patina (accelerated pre-weathering available)
Water Distribution	Precision-machined stainless steel weir
Pump Type	Submersible recirculation pump (included)
Flow Rate	Adjustable
Reservoir Capacity	Integrated lower basin
Electrical Requirements	Standard outdoor outlet (pump: 110-240V)
Lighting Options	Optional LED (warm white, cool white, RGB)
Mounting Options	Freestanding (standard) or wall-mounted (optional)

Applications & Uses

Setting	Description
Luxury Residences	A dramatic garden centerpiece for high-end homes
Hotel & Resort Entrances	Welcoming guests with a stunning first impression
Corporate Headquarters	Elevating office landscapes with sophisticated design
Public Parks & Plazas	A durable, low-maintenance installation for public spaces
Restaurant Outdoor Dining	Enhancing ambiance with the soothing sound of water
Rooftop Gardens	Adding vertical interest to urban outdoor spaces
Spa & Wellness Centers	Promoting relaxation through the sight and sound of water

Why Choose AHL for Corten Steel Water Features?

AHL Advantage	Benefit to You
20+ Years Steel Expertise	Deep understanding of Corten properties and fabrication
Precision Laser Cutting	Clean, accurate cutouts for crisp lettering and logos
Factory Direct Pricing	Competitive costs without middleman markup
Quality Assurance	Rigorous inspection of both steel and electrical components
Custom Design Support	Technical assistance from concept to completion
Weather-Sealed Electronics	Reliable LED performance in outdoor conditions
Global Shipping	Secure packaging for worldwide delivery

Frequently Asked Questions

Q1: Does the Corten steel rust through from constant water exposure?

A: No. Corten steel is specifically designed for weathering applications. The stable patina that forms actually protects the underlying steel from further corrosion. With proper drainage and recirculation, water features last for decades.

Q2: Will the rust stain the water or the surrounding area?

A: During initial weathering (first few months), minor runoff may occur. Once the stable patina forms, runoff ceases. The recirculating water may take on a slight amber tint initially, but it will clear. Pre-weathered or sealed options are available to eliminate initial runoff.

Q3: How noisy is the water curtain?

A: The sound is adjustable via pump speed. It can range from a gentle, soothing trickle to a more vigorous cascade. The WF09-01 is engineered for pleasant water sound—not harsh splashing.

Q4: What maintenance is required?

A: Minimal. Regular tasks include topping up water (evaporation), cleaning the pump filter monthly, and seasonal deep cleaning. The Corten steel itself requires no maintenance.

Q5: Can I use it in freezing winter climates?

A: Yes, with proper winterization. Before the first freeze, drain all water from the system, including the pump, plumbing, and reservoir. The Corten steel is freeze-thaw resistant. We provide detailed winterization instructions.

Q6: Can I customize the size?

A: Absolutely. While the WF09-01 is our standard 1500x1500mm model, we offer custom sizing to meet your specific space requirements.

Q7: Do you offer lighting options?

A: Yes. We offer integrated LED lighting in warm white, cool white, or RGB color-changing options. Lights can be positioned at the top (illuminating the water curtain) or within the reservoir (uplighting effect).

Q8: How is the water distributed evenly?

A: The WF09-01 features a precision-machined stainless steel weir that ensures uniform water flow across the full 1471.5mm width, creating a seamless curtain without gaps.

Q9: Can I install it myself?

A: While basic installation is possible for experienced DIYers, we recommend professional installation for electrical connections and proper wall mounting, especially for larger units.

Q10: What pump is included?

A: We include a high-quality, energy-efficient submersible pump sized specifically for your water curtain. Pump specifications vary based on final height and flow requirements.

1. Weathering steel is a pre-weathering material that can be used outdoors for decades;

2. We have our own raw materials, processing equipment, engineers and skilled workers to ensure quality and after-sales service;

3. The company can customize LED lights, fountains, water pumps and other functions according to customer requirements.
